Features:

1. Space-saving design.
2. Faster printing speed, 6 inches 152 mm/s, to improve the daily efficiency.
3. 8MB SDRAM & 8MB Flash memory for a more flexible usage.
4. Support emulation language compatibility: TSPL, ZPL, EPL, DPL

Specifications:

1. Model: XP-D4601B
2. Resolution: 203 DPI
3. Print method: Direct Thermal
4. Print speed: 152mm(6″)/s Max.
5. Max. print width: 104mm(4.09″)
6. Max. print length: 1778 mm( 70″)
7. Media type: Continuous, gap, black mark, fan-fold and punched hole
8. Media width: 25.4 mm ~115mm
9. Media thickness: 0.06 ~ 0.254 mm (2.36 ~ 10 mil)
10. Media core diameter: 25.4 ~ 76.2 mm ( 1″ ~ 3″)
11. Label length: 10 ~ 1778 mm ( 0.39″ ~ 70″)
12. Processor: 32-bit CPU
13. Memory: 8MB Flash Memory/8MB SDRAM/Flash memory can be expanded Max. 4Gb
14. Interface: Standard version: USB Optional: Lan/WIFI/Bluetooth/TF card
15. Sensors: ①Gap②Cover opening sensor③Black mark sensor ④Ribbon sensor
16. Internal fonts: 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software
17. 1D barcode: Code39, Code93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128,UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11
18. 2D barcode: PDF-417, Maxicode, DataMatrix, QR code, Aztec.
19. Rotation: 0°, 90°, 180°,270°
20. Emulation: TSPL, EPL, ZPL, DPL
21. Dimension: 282mm(L) x 232mm (W) x 171 mm (H)
22. Weight: 1.31 kg
23. Driver: Windows/Linux/Mac.
24. SDK: Windows/iOS/Android
25. Input: AC 110-240V
26. Output: DC 24V -2.5A
27. Operation environment: 5 ~ 40℃（41 ~ 104°F）, Humidity: 25 ~ 85% non-condensing
28. Storage environment: -40 ~ 60℃（-40 ~ 140°F）, Humidity: 10 ~ 90% non-condensing
