Specifications：

1. Printing method: Direct thermal
2. Paper width: 58/80/83±0.5mm
3. Print width: 72mm/76mm/80mm/64mm/48mm/52mm
4. Paper roll diameter: Min: 13mm Max: 83mm
5. Column capacity: 576 dots/line (adjustable by command)
6. Printing speed: 300 mm/s
7. Interface: USB+Serial+Lan (Optional: Bluetooth/WIFI)
8. Line spacing: 3.75mm (adjustable by commands)
9. Column number: 80mm paper: FontA-42 columns or 48 columns/Font B – 56 columns or 64 columns / Chinese, traditional Chinese – 21 columns or 24 columns
10. Character size: ANK, Font A: 1.5 x 3.0 mm (12 x 24 dots) Font B: 1.1 x 2.1 mm ( 9 x 17 dots) Chinese, traditional Chinese: 3.0 x 3.0 mm ( 24 x 24 dots)
11. Auto cutter: Partial
12. Extension character sheet: PC347(Standard Europe)/Katakana/PC850(Multilingual)/PC860(Portuguese)/PC863(Canadian-French)/PC865(Nordic)/West Europe/Greek/ Hebrew/East Europe/Iran/WPC1252/PC866(Cyrillic#2)/PC852(Latin2)/PC858/IranII/Latvian/Arabic/PT151(1251)
13. Barcode types: UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128
14. 2D Barcode: QR CODE/PDF417
15. Input buffer: 2048 Kbytes
16. NV Flash: 256 Kbytes
17. Power adapter: Input: AC220V, 50 ~ 60Hz Output: DC24V/2.5A
18. Printer Input: DC 24V/2.5A
19. Cash drawer output: DC 24V/1A
20. Weight: 1.1 kg
21. Dimensions: 140130133mm(DWH)
22. Work environment: Temperature(0 ~ 45 ℃) humidity(10 ~ 80%)
23. Storage environment: Temperature(-10℃ ~ 60℃） humidity ( 10 ~ 80%)
24. Cutter life: 2 million cuts
25. Printer head life: 150 KM
26. Emulation: ESC/POS
27. Driver: Windows/JPOS/Linux/Android/Mac/OPOS
28. Utility: Windows & Linux test Utility
29. SDK: iOS/ Android/ Windows

Features:

1. Cutter life upgrade to 2 million cuts.
2. Printhead life upgrade to 150 km.
3. Easy Maintenance: 5S for firmware update.
4. Supports 58/80/82.5 mm paper roll width.
5. Up to 300mm/s printing speed.
6. Steady performance: Apply auto cutter error calibration and printhead overheat protection system.
7. Excellent compatibility, rich software on Windows, Linux, Mac, Android, and iOS operating system.
