Digital Hot Foil Satin Ribbon Printing Machine

Source: Kunshan TES Electronic Technology Co., Ltd.2021-03-16

D4022 Satin ribbon printer
Features:

  1. Customized ribbon printer, instead of printing, beautiful ribbon, easy to get!
  2. A wide range of printing materials, printing quickly, small and exquisite.
  3. Application: Flower Ribbon, gift packaging ribbon, ceremonial ribbon, funeral ribbon.

Specifications:

  1. Model: D4022
  2. Print width: not more than 104mm
  3. Media width: 15-115 mm
  4. Print length: 10-6000mm
  5. Max roll outer diameter: 125mm
  6. Media sensor: Transmittance sensor
  7. Operational temperature: 5℃ – 50 ℃
  8. Operational humidity: 25% ~ 85% RH (non-condensing)
  9. Storage temperature: -20℃ – 60 ℃
  10. Storage humidity: 10% – 90% RH (non-condensing)
  11. Resolution ratio: 203 dpi
  12. Font: Nmark0, Nmark1, Nmark2, Nmark3, Nmark4, Nmark5, 宋体,黑体, Times Roman, Arial
  13. CPU: 32-bit CPU
  14. Print speed: 5 inch/s
  15. Dimensions/ Item weight: 310mm(L) x 235mm (W) x 204mm (H) / 2.7 KG
  16. Programming language: NPL compatible with TPCL and TSPL
  17. Storage: RAM: 16M ROM: 16M
  18. Operational mode: batch/ label
  19. Print head: flat-pressed
  20. Print mode: direct thermal tto
  21. Connection: USB、Network、Serial
  22. TDcode type: QR code, DataMatrix, PDF417 Maxicode, MicroPDF417
  23. Attachment: USB、DC adapter、Instruction
